The John Deere LX172 is a lawn and garden tractor from the John Deere LX100-series. The John Deere LX172 garden tractor was produced at the John Deere Horicon Works plant (Horicon, Wisconsin, USA) from 1990 to 1997.
- Manuals & Training Ag, Turf, & Engine Operator Manuals & Publications Discover how to find, view, and purchase technical and service manuals and parts catalogs for your John Deere equipment.
- 1.000.000+ free PDF manuals from more than 10.000 brands. Search and view your manual for free or ask other product owners.
- Interestingly the JD LX172 is almost exactly identical to the John Deere LX176. The only difference between the 2 is the transmission. While the JD LX176 uses a hydrostatic transmission which makes it an automatic, the transmission on the LX172 gives it 5 different speeds going forward and one for reversing. It’s top speed is 8.4 kph (5.2 mph).
Service Schedule Parts for a John Deere LX172 Lawn Tractor & Parts List. While your John Deere machine is certainly built with quality parts, they have a limited life. Good news is you can easily service your machine yourself using a John Deere maintenance kit or service kits or by getting the specific John Deere part needed to keep your John Deere mower or tractor running for a long time.
The John Deere LX172 tractor used an air-cooled single-cylinder four-stroke Kawasaki FC420V gasoline engine with vertical PTO shaft. The FC420V engine has an OHV (overhead valve) design; cast-iron cylinder liner; reciprocating balancer; float type carburetor with fixed main jet; flywheel magneto transistor type ignition system; mechanical governor. An 89.0 mm (3.5 in) cylinder bore and 68.0 mm (2.68 in) piston stroke give the motor a total of 423 cc of displacement. Compression ratio rating is 8.4:1. The Kawasaki FC420V motor produced 14.0 HP (10.4 kW) at 3,600 rpm of horsepower and 30.6 Nm (3.12 kg·m; 22.58 ft·lb) at 2,400 rpm of torque.
The John Deere LX172 is equipped with Peerless 801 gear type transmission with five forward and one rear gear, disc brakes, and manual sector-and-pinion steering. This tractor used open operator station, independent PTO-shaft with electric clutch and 9.5 L (2.5 US gal) fuel tank.
Following attachments are available for The John Deere LX172 garden tractor:
- Mid-mount John Deere 960.0 mm (38 in) mower deck with 2-blade and manual lift
- Front-mount John Deere 960.0 mm (38 in) single-stage snow blower
- Front-mount John Deere 1060.0 mm (42 in) single-stage snow blower
John Deere LX172 Specifications
| General Specifications | |
| Model | John Deere LX172 |
| Length | 1,670 mm (66.1 in) |
| Width | 1,260 mm (49.7 in) |
| Height | 1,020 mm (40.2 in) |
| Wheel base | 1,160 mm (45.9 in) |
| Weight | – |
| Fuel tank capacity | 9.5 L (2.5 US gal) |
| Battery | 12V |
| Engine | |
| Engine model | Kawasaki FC420V |
| Fuel | Gasoline |
| Displacement | 423 cc (25.8 cu-in) |
| Bore x stroke | 89.0 x 68.0 mm (3.5 x 2.68 in) |
| Power output | 14.0 HP (10.4 kW) at 3,600 rpm |
| Starter type | Electric starter |
| Oil type | 10W-30 |
| Oil capacity | 1.3 L (1.4 US. qt) |
| Spark plug | NGK: BPR5ES; CHAMPION: RN11YC |
| Transmission and chassis | |
| Chassis | 4×2 (2WD) |
| Transmission type | Gear transmission (Peerless 801) |
| Gears | 5 forward and 1 reverse |
| Ground speed | Forward: up to 8.4 kmh (5.2 mph) Reverse: up to 3.7 kmh (2.3 mph) |
| Transmission oil capacity | 1.0 L (1.1 qts) |
| PTO-shaft | |
| PTO type | Front, independent with electric clutch |
| PTO speed | 3,600 |
| Wheels and tires | |
| Front tires | Lawn/turf: 15×6.00-6 |
| Rear tires | Lawn/turf: 20×10.00-8 |
